Voltage: AC100-240V 50/60HZ
Light source: MSD230W, philip bubble
Total power: 350W
Fuse: 7A
Channel: 16 channels
Carton packaging size: 460 x 385 x 550mm
Net weight: 17kg
Gross weight: 19kg
16 megapixel color LCD touch screen,
Both touch mode and non-contact roller operation mode
Support multiple languages ＆#8203;＆#8203;(8 languages) environment.
Can be inverted 180° display
Color plate: A color plate, each color plate consists of 9 color chips.
(8 colors + white light) color chips can be exchanged.
Pattern plate: 1 fixed pattern plate, fixed pattern plate with 17 replaceable pattern pieces
Prism system: a unique prism system with rotating positioning.
Atomization: linear atomization, pulse atomization
Motorized focus, beam angle 0~4°
Both horizontal and vertical are driven by a three-phase motor for smoother operation and less noise.
With the photoelectric reset system, the reset can be automatically retrieved after accidental misoperation.
Level 540°, resolution 8Bit/16Bit, vertical 270°, resolution 8Bit/16Bit
The communication is designed to be compatible with the standard DMX512 protocol.
Support multi-network integration (DMX, wireless, Ethernet) functions.
Support RDM control protocol, remote device management through software.
Overheating protection
