Voltage: 100V-240V/50-60Hz, ballast: electronic music ballast
Power: 350W
Light bulb: OSRAM SIRIUS HRI 330W (optional YODN R17 350W)
Color temperature: 7500K
Average life: 1500 hours
Number of channels: 23Channels
Protection level: Ip20
Size: 409 × 419 × 541mm
Weight: 23 kg
Control mode: 23 international standard DMX512 control, master-slave mode, self-propelled mode.
LCD liquid crystal display, DMX 3- or 5-core signal input
Lens: Yiyi anti-reflection coated glass lens
Color: With 6 colors + blank, with full color or half color function,
At the same time, it has UV insulation film, CMY color mixing system.
Fixed pattern: with 14 fixed pattern pieces + blank
Rotating pattern: With 8 rotating patterns plus blank, the pattern piece can be freely inserted and replaced
Strobe: 0-13 times / sec. With random strobe
Prism and prism rotation: Rotate the 3-sided prism, which can rotate in both directions and rotate the prism.
With 16 prism macro function
Soft light effect: the angle of the spot that can adjust the soft light
Aperture: 5% to 100% with aperture effect
Focusing: Linear electronic focusing
Dimming: 0-100% linear adjustment
Projected light range: X-direction 540 degrees, Y-direction 270 degrees, automatic correction positioning
Beam angle: 5.4° to 28°
Strobe: Two-chip strobe (0.5-9 times / sec)
Number of motors: A total of 16 ultra-quiet motors, two three-phase motors, 16Bit drive
Other functions: Remote control of the light bulb switch function, display lamp, bulb usage time
Appearance: High temperature resistant plastic + molded alloy material
